Magnetic PCB Mounted Jack Shielded

RJ45 JACK 1X1 LED WITH TRANSFORMER L:32.5

RJ45 JACK 1X1 LED WITH TRANSFORMER L:32.5

Datasheet Download:
RJ45 Modular Jack 1X1 LED SHIELDED With Transformer

MATERIAL:
1. HOUSING MATERIAL: PBT,PA66(UL 94V-0)
2. CONTACT MATERIAL : FLAT PINS-0.35mm THICKNESS PHOSPHOR BRONZE;
3. PLATING: GOLD PLATING OVER NICKEL/Selective gold 6u”Min
4. SHIELD : 0.2mm THICKNESS COPPER ALLOY WITH NICKEL PLATED
5. LED : OPTION
ELECTRICAL/PHYSICAL:
1.INSERTION LOSS : -1.0dB Max @1.0-100MHz
-1.2dB Max @100-125MHz
2.RETURN LOSS : -20dB Min @1-30MHz
-16dB Min @30-60MHz
-12dB Min @60-80MHz
-10dB Min @80-100MHz
3.CROSS TALK : -40dB Min @1-30MHz
-35dB Min @30-60MHz
-30dB Min @60-100MHz
4.CMR : -30dB Min @1-50MHz
-20dB Min @50-159MHz
5.HI-POT : 1500Vrms 1mA MAX
6.TURN RATIO : 1CT:1CT (+/-2%)
7.OCL : 350uH Min @100KHz/0.1V DC BIAS 8mA
8.OPERA TING TEMPERATURE RANGE : 0-70° C
